- ISO Code: TPGW110302-3S (ANSI: TPGW2.51.5-3S)
- Grade: CD6100 (High-content PCBN composite substrate engineered for extreme thermal oxidation resistance and flank wear resistance in ISO H and K materials)
- Machining Type: Precision fine finishing, light internal hard boring, external turning, and mirror profiling
- Service: OEM & ODM
DESCRIPTION
Product Overview
The TPGW110302-3S CD6100 is a high-precision 60-degree triangular PCBN (Polycrystalline Cubic Boron Nitride) turning insert engineered for ultra-fine finish turning and light internal boring of Hardened Steel (HRC 45–65), High-Chromium Cast Iron, and Powder Metallurgy Metals. Featuring an ultra-sharp 0.2mm nose radius (R0.2), an 11-degree positive clearance angle, and 3 fully indexable solid CBN cutting tips (-3S), this G-class precision-ground insert generates minimal cutting resistance. It empowers machine shops to replace cylindrical grinding with direct, high-efficiency hard turning to achieve mirror-like surface finishes.
Technical Specifications
ISO Code: TPGW110302-3S (ANSI: TPGW2.51.5-3S)
Grade: CD6100 (High-content PCBN composite substrate engineered for extreme thermal oxidation resistance and flank wear resistance in ISO H and K materials)
Shape: T-Shape (60 Degree Triangle)
Relief Angle: P-Type (11 Degree Positive clearance – drastically lowers cutting forces and spindle torque)
Cutting Corner Configuration: 3-Corner Solid PCBN Tips (-3S)
Inscribed Circle: 6.35 mm (1/4 inch)
Thickness: 3.18 mm
Nose Radius: 0.2 mm (R0.2 / 1/128 inch) – Micro-radius for extreme precision, tight dimensional control, and mirror-smooth surface quality
Machining Type: Precision fine finishing, light internal hard boring, external turning, and mirror profiling
Applications
Workpiece Materials: Hardened Steel (HRC 45–65), Case Hardened Steel, Bearing Steel, Tool Steel, and High-Strength Cast Iron.
Industries: Automotive (gears, shafts, bearings), Aerospace, and Mold & Die manufacturing.
Cutting Conditions: Primarily used for Hard Part Turning (HPT) in continuous or slightly interrupted cutting applications.
